Use the MDL Online Part Selector

Make your life easier, speed up the process, and get more accurate information.

Do you know your die's engagement height? Use the MDL Part Selector.



Do you know your die's
"Engagement Height"?

Engagement height is the height of your die (measured from top of upper shoe to bottom of lower shoe, no parallels) at which time the working diameters of the pin and bushings cross and the balls on ball bearing die sets start rolling.



This is an important piece of information as the rule of thumb is for a die to be engaged
to at least the same dimension as the nominal diameter of the pins being used
(some say 1 1/2 times the nominal diameter) before punches and cutting steels enter.



Die designers that have been using the MDL Online Part Selector for selecting ball bearings components have been getting the Engagement Height information on "D" Style components (interchangeable with "Danly") automatically for years, but not for "L" Style components (interchangeable with "Lamina").



That has now changed and designers using the MDL Part Selector will automatically get the Engagement Height along with the appropriate pin, bushing, and ball cage for a particular application ("L" or "D" Style). Bore size recommendations for the pins and bushings will continue to be displayed along with the part number.



All a designer has to do is USE THE MDL PART SELECTOR
and all this information is at your fingertips, for FREE!

Try the Part Selector



Register today to make your life easier, speed up the process,
and get more accurate information.

www.mdlcomponents.com



MDL Components


MDL Components
QUALITY, DELIVERY, & VALUE
used WORLDWIDE!

MDL Components-Committed to the "D" & "L" Style product platforms-
Yesterday, Today, & TOMORROW!



Note: MDL “D” Style Ball Bearing Components are designed to be interchangeable with ball bearing components from “Danly” of the same size and type.

DANLY is a registered trademark of Anchor Lamina America, Inc.. MDL Mold & Die Components, Inc. is not connected in any way to DANLY or Anchor Lamina America, Inc..



Note: MDL "L" Style Ball Bearing Components are designed to be interchangeable with ball bearing components from "Lamina" of the same size and type.

LAMINA is a registered trademark of Anchor Lamina America, Inc.. MDL Mold & Die Components, Inc. is not connected in any way to LAMINA or Anchor Lamina America, Inc..
